XPENG G9 AWD Performance

Model: XPENG


  • Warning: Undefined array key "spec_key" in /home/bike-ev.com/public_html/wp-content/themes/bike_ev_template/single-vehicle.php on line 50
    :
    93.1 kWh *

  • Warning: Undefined array key "spec_key" in /home/bike-ev.com/public_html/wp-content/themes/bike_ev_template/single-vehicle.php on line 50
    :
    465 km

  • Warning: Undefined array key "spec_key" in /home/bike-ev.com/public_html/wp-content/themes/bike_ev_template/single-vehicle.php on line 50
    :
    200 Wh/km

Real Range

City - Cold Weather465 km
Highway - Cold Weather335 km
Combined - Cold Weather395 km

between 335 - 675 km

City - Mild Weather675 km
Highway - Mild Weather430 km
Combined - Mild Weather530 km

Performance

Acceleration 0 - 100 km/h3.9 sec
Top Speed200 km/h
Electric Range465 km
Total Power405 kW (551 PS)
Total Torque717 Nm
DriveAWD

Battery

Nominal Capacity98.0 kWh
Battery TypeLithium-ion
Number of CellsNo Data
Architecture800 V
Warranty PeriodNo Data
Warranty MileageNo Data
Useable Capacity*93.1 kWh
Cathode MaterialNCM
Pack ConfigurationNo Data
Nominal VoltageNo Data
Form FactorNo Data
Name / ReferenceNo Data

Bidirectional Charging (V2X / BPT)

Vehicle-to-Load (V2L)

V2L SupportedYes
Max. Output Power3.3 kW AC

Vehicle-to-Home (V2H)

V2H via AC SupportedNo
Max. Output Power-

Vehicle-to-Grid (V2G)

V2G via AC SupportedNo
Max. Output Power-

Energy Consumption

EVDB Real Range

Range465 km
Vehicle Consumption200 Wh/km

WLTP Ratings

Range520 km
Rated Consumption213 Wh/km
Vehicle Consumption179 Wh/km

Dimensions and Weight

Length4891 mm
Width1937 mm
Width with mirrorsNo Data
Height1670 mm
Wheelbase2998 mm
Weight Unladen (EU)2415 kg
Gross Vehicle Weight (GVWR)2800 kg
Max. Payload460 kg
Cargo Volume660 L
Cargo Volume Max1576 L
Cargo Volume Frunk71 L
Roof LoadNo Data
Tow Hitch PossibleYes
Towing Weight Unbraked750 kg
Towing Weight Braked1500 kg
Vertical Load Max75 kg

Miscellaneous

Seats 5 people
IsofixYes, 2 seats
Turning CircleNo Data
PlatformXPENG X-EEA3.0
EV Dedicated PlatformYes
Car BodySUV
SegmentJE - Executive
Roof RailsYes
Heat pump (HP)Yes
HP Standard EquipmentYes

Home and Destination Charging (0 -> 100%)

Charging is possible by using a regular wall plug or a charging station. Public charging is always done through a charging station. How fast the EV can charge depends on the charging station (EVSE) used and the maximum charging capacity of the EV. The table below shows all possible options for charging the XPENG G9 AWD Performance. Each option shows how fast the battery can be charged from empty to full.

Europe

Charging an EV in Europe differs by country. Some European countries primarily use 1-phase connections to the grid, while other countries are almost exclusively using a 3-phase connection. The table below shows all possible ways the XPENG G9 AWD Performance can be charged, but some modes of charging might not be widely available in certain countries.

Type 2 (Mennekes - IEC 62196)
Charging PointMax. PowerPowerTimeRate
Wall Plug (2.3 kW)230V / 1x10A2.3 kW47h45m10 km/h
1-phase 16A (3.7 kW)230V / 1x16A3.7 kW29h45m16 km/h
1-phase 32A (7.4 kW)230V / 1x32A7.4 kW15 hours31 km/h
3-phase 16A (11 kW)400V / 3x16A11 kW10 hours47 km/h
3-phase 32A (22 kW)400V / 3x16A11 kW †10 hours47 km/h

† = Limited by on-board charger, vehicle cannot charge faster.

Fast Charging (10 -> 80%)

Rapid charging enables longer journeys by adding as much range as possible in the shortest amount of time. Charging power will decrease significantly after 80% state-of-charge has been reached. A typical rapid charge therefore rarely exceeds 80% SoC. The rapid charge rate of an EV depends on the charger used and the maximum charging power the EV can handle. The table below shows all details for rapid charging the XPENG G9 AWD Performance.

  • Max. Power: maximum power provided by charge point
  • Avg. Power: average power provided by charge point over a session from 10% to 80%
  • Time: time needed to charge from 10% to 80%
  • Rate: average charging speed over a session from 10% to 80%
Combined Charging System (CCS Combo 2)
Charging PointMax. PowerAvg. PowerTimeRate
CCS (50 kW DC)50 kW50 kW82 min230 km/h
CCS (150 kW DC)150 kW150 kW27 min720 km/h
CCS (350 kW DC)319 kW †224 kW †18 min1080 km/h
Charge Curve

Data made available by Fastned

This vehicle supports Autocharge
This vehicle does not support Plug & Charge

† = Limited by charging capabilities of vehicle

Autocharge: allows for automatic initiation of a charging session at supported CCS charging stations.

Plug & Charge: allows for automatic initiation of a charging session at supported CCS charging stations in accordance with ISO 15118.

Actual charging rates may differ from data shown due to factors like outside temperature, state of the battery and driving style.

XPENG Claimed Specifications

The table below shows the claimed specifications from the manufacturer for charging the XPENG G9 AWD Performance. The specifications can differ from the table above for a variety of reasons. If real-world charge tests are available, these differences can be signifcant. If no real-world tests are available, the table above will be based on the manufacturer specifications as per the table below.

  • Max. Power: maximum charge power during charging session
  • Charge From: battery percentage (% SoC) where charging session is started
  • Charge To: battery percentage (% SoC) where charging session is ended
  • Time: time needed for charging session
XPENG Claimed Specifications
Max. PowerCharge FromCharge ToTime
300 kW 10 % 80 % 20 min
