Voyah Free 106 kWh
Model: Voyah
- : 100.0 kWh
- : 480 km *
- : 208 Wh/km *
Real Range Estimation
| City - Cold Weather * | 480 km |
| Highway - Cold Weather * | 345 km |
| Combined - Cold Weather * | 410 km |
between 345 - 690 km
| City - Mild Weather * | 690 km |
| Highway - Mild Weather * | 435 km |
| Combined - Mild Weather * | 540 km |
Performance
| Acceleration 0 - 100 km/h | 4.4 sec |
| Top Speed | 200 km/h |
| Electric Range * | 480 km |
| Total Power | 360 kW (489 PS) |
| Total Torque | 720 Nm |
| Drive | AWD |
Battery
| Nominal Capacity | 106.0 kWh |
| Battery Type | Lithium-ion |
| Number of Cells | No Data |
| Architecture | 400 V |
| Warranty Period | 8 years |
| Warranty Mileage | 160,000 km |
| Useable Capacity | 100.0 kWh |
| Cathode Material | No Data |
| Pack Configuration | No Data |
| Nominal Voltage | No Data |
| Form Factor | No Data |
| Name / Reference | No Data |
Bidirectional Charging (V2X / BPT)
Vehicle-to-Load (V2L)
| V2L Supported | No |
| Max. Output Power | - |
Vehicle-to-Home (V2H)
| V2H via AC Supported | No |
| Max. Output Power | - |
Vehicle-to-Grid (V2G)
| V2G via AC Supported | No |
| Max. Output Power | - |
Energy Consumption
EVDB Real Range
| Range * | 480 km |
| Vehicle Consumption * | 208 Wh/km |
WLTP Ratings
| Range | 500 km |
| Rated Consumption | 202 Wh/km |
| Vehicle Consumption | 200 Wh/km |
Dimensions and Weight
| Length | 4905 mm |
| Width | 1950 mm |
| Width with mirrors | No Data |
| Height | 1645 mm |
| Wheelbase | 2960 mm |
| Weight Unladen (EU) | 2415 kg |
| Gross Vehicle Weight (GVWR) | 2945 kg |
| Max. Payload | 605 kg |
| Cargo Volume | 550 L |
| Cargo Volume Max | 1320 L |
| Cargo Volume Frunk | 72 L |
| Roof Load | 75 kg |
| Tow Hitch Possible | Yes |
| Towing Weight Unbraked | 750 kg |
| Towing Weight Braked | 2000 kg |
| Vertical Load Max | No Data |
Miscellaneous
| Seats | 5 people |
| Isofix | Yes, 2 seats |
| Turning Circle | 11.5 m |
| Platform | DONGFENG ESSA |
| EV Dedicated Platform | No |
| Car Body | SUV |
| Segment | JE - Executive |
| Roof Rails | Yes |
| Heat pump (HP) | No |
| HP Standard Equipment | - |
Home and Destination Charging (0 -> 100%)
Charging is possible by using a regular wall plug or a charging station. Public charging is always done through a charging station. How fast the EV can charge depends on the charging station (EVSE) used and the maximum charging capacity of the EV. The table below shows all possible options for charging the Voyah Free 106 kWh. Each option shows how fast the battery can be charged from empty to full.
Europe
Charging an EV in Europe differs by country. Some European countries primarily use 1-phase connections to the grid, while other countries are almost exclusively using a 3-phase connection. The table below shows all possible ways the Voyah Free 106 kWh can be charged, but some modes of charging might not be widely available in certain countries.
| Type 2 (Mennekes - IEC 62196) |
|---|
 |
| Charging Point | Max. Power | Power | Time | Rate |
|---|---|---|---|---|
| Wall Plug (2.3 kW) | 230V / 1x10A | 2.3 kW | 51h15m | 9 km/h |
| 1-phase 16A (3.7 kW) | 230V / 1x16A | 3.7 kW | 32 hours | 15 km/h |
| 1-phase 32A (7.4 kW) | 230V / 1x32A | 7.4 kW | 16 hours | 30 km/h |
| 3-phase 16A (11 kW) | 400V / 3x16A | 11 kW | 10h45m | 45 km/h |
| 3-phase 32A (22 kW) | 400V / 3x16A | 11 kW † | 10h45m | 45 km/h |
† = Limited by on-board charger, vehicle cannot charge faster.
Fast Charging (10 -> 80%)
Rapid charging enables longer journeys by adding as much range as possible in the shortest amount of time. Charging power will decrease significantly after 80% state-of-charge has been reached. A typical rapid charge therefore rarely exceeds 80% SoC. The rapid charge rate of an EV depends on the charger used and the maximum charging power the EV can handle. The table below shows all details for rapid charging the Voyah Free 106 kWh.
Voyah has not released details about rapid charging the Free. The information below is based on estimated values of the most likely rapid charging capabilities.
- Max. Power: maximum power provided by charge point
- Avg. Power: average power provided by charge point over a session from 10% to 80%
- Time: time needed to charge from 10% to 80%
- Rate: average charging speed over a session from 10% to 80%
| Combined Charging System (CCS Combo 2) |
|---|
 |
| Charging Point | Max. Power | Avg. Power | Time | Rate |
|---|---|---|---|---|
| CCS (50 kW DC) | 50 kW | 45 kW † | 98 min | 200 km/h |
| CCS (100 kW DC) | 100 kW | 80 kW † | 55 min | 360 km/h |
| CCS (150 kW DC) | 100 kW † | 80 kW † | 55 min | 360 km/h |
| This vehicle does not support Plug & Charge |
|---|
† = Limited by charging capabilities of vehicle
Plug & Charge: allows for automatic initiation of a charging session at supported CCS charging stations in accordance with ISO 15118.
Actual charging rates may differ from data shown due to factors like outside temperature, state of the battery and driving style.
