Tesla Model Y
Model: Tesla
- : 57.5 kWh *
- : 350 km
- : 164 Wh/km
Real Range
| City - Cold Weather | 335 km |
| Highway - Cold Weather | 250 km |
| Combined - Cold Weather | 290 km |
between 250 - 510 km
| City - Mild Weather | 510 km |
| Highway - Mild Weather | 325 km |
| Combined - Mild Weather | 400 km |
Performance
| Acceleration 0 - 100 km/h | 6.9 sec |
| Top Speed | 217 km/h |
| Electric Range | 350 km |
| Total Power | 220 kW (299 PS) |
| Total Torque | 420 Nm |
| Drive | Rear |
Battery
| Nominal Capacity* | 60.0 kWh |
| Battery Type | Lithium-ion |
| Number of Cells | No Data |
| Architecture | 400 V |
| Warranty Period | 8 years |
| Warranty Mileage | 160,000 km |
| Useable Capacity* | 57.5 kWh |
| Cathode Material | LFP |
| Pack Configuration | No Data |
| Nominal Voltage | No Data |
| Form Factor | Prismatic |
| Name / Reference | BYD BLADE |
Bidirectional Charging (V2X / BPT)
Vehicle-to-Load (V2L)
| V2L Supported | No |
| Max. Output Power | - |
Vehicle-to-Home (V2H)
| V2H via AC Supported | No |
| Max. Output Power | - |
Vehicle-to-Grid (V2G)
| V2G via AC Supported | No |
| Max. Output Power | - |
Energy Consumption
EVDB Real Range
| Range | 350 km |
| Vehicle Consumption | 164 Wh/km |
WLTP Ratings (TEL)
| Range | 455 km |
| Rated Consumption | 157 Wh/km |
| Vehicle Consumption | 126 Wh/km |
WLTP Ratings (TEH)
| Range | 430 km |
| Rated Consumption | No Data |
| Vehicle Consumption | 134 Wh/km |
Dimensions and Weight
| Length | 4751 mm |
| Width | 1921 mm |
| Width with mirrors | 2129 mm |
| Height | 1624 mm |
| Wheelbase | 2890 mm |
| Weight Unladen (EU) | 1992 kg |
| Gross Vehicle Weight (GVWR) | 2456 kg |
| Max. Payload | 539 kg |
| Cargo Volume | 854 L |
| Cargo Volume Max | 2158 L |
| Cargo Volume Frunk | 117 L |
| Roof Load | 75 kg |
| Tow Hitch Possible | Yes |
| Towing Weight Unbraked | 750 kg |
| Towing Weight Braked | 1600 kg |
| Vertical Load Max | 72 kg |
Miscellaneous
| Seats | 5 people |
| Isofix | Yes, 2 seats |
| Turning Circle | 12.1 m |
| Platform | TESLA 3/Y |
| EV Dedicated Platform | Yes |
| Car Body | SUV |
| Segment | JD - Large |
| Roof Rails | No |
| Heat pump (HP) | Yes |
| HP Standard Equipment | Yes |
Home and Destination Charging (0 -> 100%)
Charging is possible by using a regular wall plug or a charging station. Public charging is always done through a charging station. How fast the EV can charge depends on the charging station (EVSE) used and the maximum charging capacity of the EV. The table below shows all possible options for charging the Tesla Model Y. Each option shows how fast the battery can be charged from empty to full.
Europe
Charging an EV in Europe differs by country. Some European countries primarily use 1-phase connections to the grid, while other countries are almost exclusively using a 3-phase connection. The table below shows all possible ways the Tesla Model Y can be charged, but some modes of charging might not be widely available in certain countries.
| Type 2 (Mennekes - IEC 62196) |
|---|
 |
| Charging Point | Max. Power | Power | Time | Rate |
|---|---|---|---|---|
| Wall Plug (2.3 kW) | 230V / 1x10A | 2.3 kW | 29h30m | 12 km/h |
| 1-phase 16A (3.7 kW) | 230V / 1x16A | 3.7 kW | 18h30m | 19 km/h |
| 1-phase 32A (7.4 kW) | 230V / 1x32A | 7.4 kW | 9h15m | 38 km/h |
| 3-phase 16A (11 kW) | 400V / 3x16A | 11 kW | 6h15m | 56 km/h |
| 3-phase 32A (22 kW) | 400V / 3x16A | 11 kW † | 6h15m | 56 km/h |
† = Limited by on-board charger, vehicle cannot charge faster.
Fast Charging (10 -> 80%)
Rapid charging enables longer journeys by adding as much range as possible in the shortest amount of time. Charging power will decrease significantly after 80% state-of-charge has been reached. A typical rapid charge therefore rarely exceeds 80% SoC. The rapid charge rate of an EV depends on the charger used and the maximum charging power the EV can handle. The table below shows all details for rapid charging the Tesla Model Y.
- Max. Power: maximum power provided by charge point
- Avg. Power: average power provided by charge point over a session from 10% to 80%
- Time: time needed to charge from 10% to 80%
- Rate: average charging speed over a session from 10% to 80%
| Combined Charging System (CCS Combo 2) |
|---|
 |
| Charging Point | Max. Power | Avg. Power | Time | Rate |
|---|---|---|---|---|
| CCS (50 kW DC) | 50 kW | 50 kW | 51 min | 280 km/h |
| Supercharger v2 Shared (75 kW DC) | 75 kW | 70 kW † | 36 min | 400 km/h |
| Supercharger v2 (150 kW DC) | 150 kW | 120 kW † | 21 min | 700 km/h |
| CCS (175 kW DC) | 175 kW | 140 kW † | 18 min | 810 km/h |
| Supercharger v3 (250 kW DC) | 175 kW † | 140 kW † | 18 min | 810 km/h |
| CCS (350 kW DC) | 175 kW † | 140 kW † | 18 min | 810 km/h |
| This vehicle supports Autocharge |
|---|
| This vehicle does not support Plug & Charge |
† = Limited by charging capabilities of vehicle
Autocharge: allows for automatic initiation of a charging session at supported CCS charging stations.
Plug & Charge: allows for automatic initiation of a charging session at supported CCS charging stations in accordance with ISO 15118.
Actual charging rates may differ from data shown due to factors like outside temperature, state of the battery and driving style.
