Opel Grandland 82 kWh

Model: Opel

  • : 82.2 kWh
  • : 410 km *
  • : 200 Wh/km *

Real Range Estimation

City - Cold Weather *410 km
Highway - Cold Weather *290 km
Combined - Cold Weather *350 km

between 290 - 600 km

City - Mild Weather *600 km
Highway - Mild Weather *370 km
Combined - Mild Weather *465 km

Performance

Acceleration 0 - 100 km/h9.0 sec
Top Speed170 km/h
Electric Range *410 km
Total Power157 kW (213 PS)
Total Torque260 Nm
DriveFront

Battery

Nominal Capacity*86.0 kWh
Battery TypeLithium-ion
Number of CellsNo Data
Architecture400 V
Warranty Period8 years
Warranty Mileage160,000 km
Useable Capacity82.2 kWh
Cathode MaterialNCM
Pack ConfigurationNo Data
Nominal VoltageNo Data
Form FactorNo Data
Name / ReferenceNo Data

Bidirectional Charging (V2X / BPT)

Vehicle-to-Load (V2L)

V2L SupportedNo
Max. Output Power-

Vehicle-to-Home (V2H)

V2H via AC SupportedNo
Max. Output Power-

Vehicle-to-Grid (V2G)

V2G via AC SupportedNo
Max. Output Power-

Energy Consumption

EVDB Real Range

Range *410 km
Vehicle Consumption *200 Wh/km

WLTP Ratings (TEL)

Range583 km
Rated Consumption177 Wh/km
Vehicle Consumption141 Wh/km

WLTP Ratings (TEH)

Range564 km
Rated Consumption185 Wh/km
Vehicle Consumption146 Wh/km

Dimensions and Weight

Length4650 mm
Width1934 mm
Width with mirrors2103 mm
Height1665 mm
Wheelbase2795 mm
Weight Unladen (EU)2220 kg
Gross Vehicle Weight (GVWR)2700 kg
Max. Payload555 kg
Cargo Volume550 L
Cargo Volume Max1645 L
Cargo Volume Frunk0 L
Roof Load80 kg
Tow Hitch PossibleYes
Towing Weight Unbraked750 kg
Towing Weight Braked1200 kg
Vertical Load Max80 kg

Miscellaneous

Seats 5 people
IsofixYes, 3 seats
Turning Circle11.6 m
PlatformSTLA MEDIUM
EV Dedicated PlatformYes
Car BodySUV
SegmentJC - Medium
Roof RailsYes
Heat pump (HP)Yes
HP Standard EquipmentVaries by country

Home and Destination Charging (0 -> 100%)

Charging is possible by using a regular wall plug or a charging station. Public charging is always done through a charging station. How fast the EV can charge depends on the charging station (EVSE) used and the maximum charging capacity of the EV. The table below shows all possible options for charging the Opel Grandland 82 kWh. Each option shows how fast the battery can be charged from empty to full.

Europe

Charging an EV in Europe differs by country. Some European countries primarily use 1-phase connections to the grid, while other countries are almost exclusively using a 3-phase connection. The table below shows all possible ways the Opel Grandland 82 kWh can be charged, but some modes of charging might not be widely available in certain countries.

Type 2 (Mennekes - IEC 62196)
Charging PointMax. PowerPowerTimeRate
Wall Plug (2.3 kW)230V / 1x10A2.3 kW42h15m10 km/h
1-phase 16A (3.7 kW)230V / 1x16A3.7 kW26h15m16 km/h
1-phase 32A (7.4 kW)230V / 1x32A7.4 kW13h15m31 km/h
3-phase 16A (11 kW)400V / 3x16A11 kW9 hours46 km/h
3-phase 32A (22 kW)400V / 3x16A11 kW †9 hours46 km/h

† = Limited by on-board charger, vehicle cannot charge faster.

Fast Charging (10 -> 80%)

Rapid charging enables longer journeys by adding as much range as possible in the shortest amount of time. Charging power will decrease significantly after 80% state-of-charge has been reached. A typical rapid charge therefore rarely exceeds 80% SoC. The rapid charge rate of an EV depends on the charger used and the maximum charging power the EV can handle. The table below shows all details for rapid charging the Opel Grandland 82 kWh.

  • Max. Power: maximum power provided by charge point
  • Avg. Power: average power provided by charge point over a session from 10% to 80%
  • Time: time needed to charge from 10% to 80%
  • Rate: average charging speed over a session from 10% to 80%
Combined Charging System (CCS Combo 2)
Charging PointMax. PowerAvg. PowerTimeRate
CCS (50 kW DC)50 kW45 kW †81 min210 km/h
CCS (100 kW DC)100 kW80 kW †45 min380 km/h
CCS (150 kW DC)150 kW95 kW †38 min450 km/h
CCS (175 kW DC)160 kW †100 kW †36 min470 km/h
CCS (350 kW DC)160 kW †100 kW †36 min470 km/h
This vehicle supports Autocharge
This vehicle does not support Plug & Charge

† = Limited by charging capabilities of vehicle

Autocharge: allows for automatic initiation of a charging session at supported CCS charging stations.

Plug & Charge: allows for automatic initiation of a charging session at supported CCS charging stations in accordance with ISO 15118.

Actual charging rates may differ from data shown due to factors like outside temperature, state of the battery and driving style.

Opel Claimed Specifications

The table below shows the claimed specifications from the manufacturer for charging the Opel Grandland 82 kWh. The specifications can differ from the table above for a variety of reasons. If real-world charge tests are available, these differences can be signifcant. If no real-world tests are available, the table above will be based on the manufacturer specifications as per the table below.

  • Max. Power: maximum charge power during charging session
  • Charge From: battery percentage (% SoC) where charging session is started
  • Charge To: battery percentage (% SoC) where charging session is ended
  • Time: time needed for charging session
Opel Claimed Specifications
Max. PowerCharge FromCharge ToTime
160 kW 20 % 80 % 29 min
