BYD TANG Flagship

Model: BYD

  • : 108.8 kWh
  • : 460 km *
  • : 237 Wh/km *

Real Range Estimation

City - Cold Weather *470 km
Highway - Cold Weather *330 km
Combined - Cold Weather *395 km

between 330 - 660 km

City - Mild Weather *660 km
Highway - Mild Weather *410 km
Combined - Mild Weather *515 km

Performance

Acceleration 0 - 100 km/h4.9 sec
Top Speed190 km/h
Electric Range *460 km
Total Power380 kW (517 PS)
Total Torque700 Nm
DriveAWD

Battery

Nominal Capacity*111.0 kWh
Battery TypeLithium-ion
Number of CellsNo Data
Architecture800 V
Warranty Period8 years
Warranty Mileage200,000 km
Useable Capacity108.8 kWh
Cathode MaterialLFP
Pack ConfigurationNo Data
Nominal Voltage640 V
Form FactorPrismatic
Name / ReferenceBYD BLADE

Bidirectional Charging (V2X / BPT)

Vehicle-to-Load (V2L)

V2L SupportedYes
Max. Output Power3.7 kW AC

Vehicle-to-Home (V2H)

V2H via AC SupportedNo
Max. Output Power-

Vehicle-to-Grid (V2G)

V2G via AC SupportedNo
Max. Output Power-

Energy Consumption

EVDB Real Range

Range *460 km
Vehicle Consumption *237 Wh/km

WLTP Ratings

Range530 km
Rated Consumption240 Wh/km
Vehicle Consumption205 Wh/km

Dimensions and Weight

Length4970 mm
Width1955 mm
Width with mirrors2130 mm
Height1745 mm
Wheelbase2820 mm
Weight Unladen (EU)2705 kg
Gross Vehicle Weight (GVWR)3204 kg
Max. Payload574 kg
Cargo Volume235 L
Cargo Volume Max1655 L
Cargo Volume Frunk0 L
Roof Load75 kg
Tow Hitch PossibleYes
Towing Weight Unbraked750 kg
Towing Weight Braked1500 kg
Vertical Load Max150 kg

Miscellaneous

Seats 7 people
IsofixYes, 2 seats
Turning Circle11.8 m
PlatformNo Data
EV Dedicated PlatformNo Data
Car BodySUV
SegmentJE - Executive
Roof RailsYes
Heat pump (HP)Yes
HP Standard EquipmentYes

Home and Destination Charging (0 -> 100%)

Charging is possible by using a regular wall plug or a charging station. Public charging is always done through a charging station. How fast the EV can charge depends on the charging station (EVSE) used and the maximum charging capacity of the EV. The table below shows all possible options for charging the BYD TANG Flagship. Each option shows how fast the battery can be charged from empty to full.

Europe

Charging an EV in Europe differs by country. Some European countries primarily use 1-phase connections to the grid, while other countries are almost exclusively using a 3-phase connection. The table below shows all possible ways the BYD TANG Flagship can be charged, but some modes of charging might not be widely available in certain countries.

Type 2 (Mennekes - IEC 62196)
Charging PointMax. PowerPowerTimeRate
Wall Plug (2.3 kW)230V / 1x10A2.3 kW55h45m8 km/h
1-phase 16A (3.7 kW)230V / 1x16A3.7 kW34h45m13 km/h
1-phase 32A (7.4 kW)230V / 1x32A7.4 kW17h30m26 km/h
3-phase 16A (11 kW)400V / 3x16A11 kW11h45m39 km/h
3-phase 32A (22 kW)400V / 3x16A11 kW †11h45m39 km/h

† = Limited by on-board charger, vehicle cannot charge faster.

Fast Charging (10 -> 80%)

Rapid charging enables longer journeys by adding as much range as possible in the shortest amount of time. Charging power will decrease significantly after 80% state-of-charge has been reached. A typical rapid charge therefore rarely exceeds 80% SoC. The rapid charge rate of an EV depends on the charger used and the maximum charging power the EV can handle. The table below shows all details for rapid charging the BYD TANG Flagship.

  • Max. Power: maximum power provided by charge point
  • Avg. Power: average power provided by charge point over a session from 10% to 80%
  • Time: time needed to charge from 10% to 80%
  • Rate: average charging speed over a session from 10% to 80%
Combined Charging System (CCS Combo 2)
Charging PointMax. PowerAvg. PowerTimeRate
CCS (50 kW DC)50 kW45 kW †107 min180 km/h
CCS (100 kW DC)100 kW80 kW †60 min320 km/h
CCS (150 kW DC)150 kW95 kW †51 min370 km/h
CCS (175 kW DC)170 kW †100 kW †48 min400 km/h
CCS (350 kW DC)170 kW †100 kW †48 min400 km/h
This vehicle supports Autocharge
This vehicle does not support Plug & Charge

† = Limited by charging capabilities of vehicle

Autocharge: allows for automatic initiation of a charging session at supported CCS charging stations.

Plug & Charge: allows for automatic initiation of a charging session at supported CCS charging stations in accordance with ISO 15118.

Actual charging rates may differ from data shown due to factors like outside temperature, state of the battery and driving style.

BYD Claimed Specifications

The table below shows the claimed specifications from the manufacturer for charging the BYD TANG Flagship. The specifications can differ from the table above for a variety of reasons. If real-world charge tests are available, these differences can be signifcant. If no real-world tests are available, the table above will be based on the manufacturer specifications as per the table below.

  • Max. Power: maximum charge power during charging session
  • Charge From: battery percentage (% SoC) where charging session is started
  • Charge To: battery percentage (% SoC) where charging session is ended
  • Time: time needed for charging session
BYD Claimed Specifications
Max. PowerCharge FromCharge ToTime
170 kW 10 % 80 % 46 min
